PS5500R

Wireless 2D CMOS Barcode Scanner

Features:

  • 640*480 pixels scan engine
  • Reads all 2D/1D Barcodes, Omni Directional Scanning
  • Reads 2D Barcodes above 5mil
  • Green Dot Aimer, White illumination
  • Trigger or Continuous Scanning Mode
  • Reads barcodes from LCD/Tablet/Smartphone’s
  • Shock Resistance- 1.8mt on Concrete surface
  • 2.4G RF , Bluetooth , USB ( 3 in 1 Mode)
  • No Data Loss mode
  • Communication Distance: ≥60 Meters（2.4G）/ 15 Meters(BT)
  • Stores up to >=12K barcodes
  • Battery Capacity: 1800Mah

Specifications

Light Source Aiming: 617 nm LED; illumination: 6500K LED
Resolution 640*480
Scanning Method Trigger, Continuous
Decode capability All 2D & 1D Barcodes
Prompt mode Buzzer, indicator light
Contrast Ratio ≥25%
Field of view 40° (H) x 34° (V)
Roll / Pitch / Yaw Roll ±360°，Pitch ±60°，Skew ±70°
Symbol & Density

EAN-13 (13mil)
Code39 (5mil)
QR (15mil)

 Range

40mm~280mm, Barcode Size：32mm*25mm
40mm~100 mm Barcode Size：25mm*10mm
30mm~210mm, Barcode Size：8mm*8mm
Anti-shock 1.8meter
Operable Frequency 2.4Ghz
Communication Distance ≥60 Meters（2.4G）/ 15 Meters(BT)
Battery 1800 mAh
Charging hours ≤4Hours
Storage Capacity ≥12000 Barcodes
